conductivity_indicators_controllerscatttani_5500_smalleranisml

Category:  Conductivity Meter Indicator Controller

SKU:  5500


Features
  • Precision indication of conductivity
  • Automatic Temperature Compensation @2%/˚C using PT-100
  • Front panel 5 range selector from 199.9ms to 19.99μs
  • Cell factor selectable, 1.0 OR 0.1 with front panel calibration facility
  • Reads T.D.S. in ppm
  • Front panel ‘touch type’ membrane switches to select Range, cell factor and T.D.S.
  • Bright RED LED display
Specification
Display 3 ½ Digit 13mm High, RED LED.
Cell Factor 1.0 & 0.1 Selectable.
Conductivity Range A)For Cell Factor 1.0
1) 199.9 mS/cm
2) 19.99 mS/cm
3) 19999 mS/cm
4) 199.9 mS/cm
: B)For Cell Factor 0.1
1) 19.99 mS/cm
2) 19999 mS/cm
3) 199.9 mS/cm
4) 19.99 mS/cm
TDS Range 2000 ppm
Temperature Compensation Automatic Using External PT-100 Sensor..
