Name: Wall Mounted Humidity and Temperature Indicator using Dry/Wet PT-100 Sensors
SKU: 7100W
Availability: InStock

Wall Mounted Humidity and Temperature Indicator using Dry/Wet PT-100 Sensors

SKU: 7100W

Download Catalogue

Description

Direct display of Humidity & Temperature using the classical DRY/WET Electronic temperature Sensors
No need of Look-Up table as the table is embedded in the micro-controller memory.
Easy to calibrate & compare with Mercury in Glass thermometer systems.
Sensors not contaminated by atmospheric gases etc. as the PT100 Sensors are sealed in steel tube.
Large 1” RED 7 Segment displays gives long distance visibility.
Rugged ABS cabinet with attractive look. Specifications

Additional information

Your custom text or HTML.

Display	2 Digits 7 Segment LEDs 1” character height (For Humidity) 3 Digits 7 Segment LEDs 1” character height (For Temp.)
Sensor	2 Nos. PT100 in sealed stainless steel tubing installed on the side of the cabinet.
Range	0 to 99% Humidity and 0 to 99.9˚C temperature
Resolution	1% For Relative Humidity & 0.1˚C for Temper
Accuracy	± 2% for RH ± 1 Least Significant Digit. ± 0.2˚C for Temperature ± 1 Least Significant Digit.
Power	230V AC ± 15%
Cabinet	Strong ABS plastic cabinet. Sensor on the side, with a side platform for water bottle of large capacity.
Water Wick	Made of pure cotton. To be used with preferably, distilled water, & slight air breeze
Size	140mm x 138mm x 55mm
Weight	700 gms.

Display:

2 Digits 7 Segment LEDs 1” character height (For Humidity) 3 Digits 7 Segment LEDs 1” character height (For Temp.)

Sensor:

2 Nos. PT100 in sealed stainless steel tubing installed on the side of the cabinet.

Range:

0 to 99% Humidity and 0 to 99.9˚C temperature

Resolution:

1% For Relative Humidity & 0.1˚C for Temper

Accuracy:

± 2% for RH ± 1 Least Significant Digit. ± 0.2˚C for Temperature ± 1 Least Significant Digit.

Power:

230V AC ± 15%

Cabinet:

Strong ABS plastic cabinet. Sensor on the side, with a side platform for water bottle of large capacity.

Water Wick:

Made of pure cotton. To be used with preferably, distilled water, & slight air breeze

Size:

140mm x 138mm x 55mm

Weight:

700 gms.
