UNIVERSAL DIGITAL TEMPERATURE CONTROLLER LOGGER

Single channel Temperature Scanner for J/K/R/PT100/4-20mA sensor with PID control and single set limit with direct USB Pen Drive output (LED Display)

Please install and activate YITH WooCommerce Wishlist to add product wishlist
Category : Data Loggers Category : Digital Temperature Controller
SKU: CT701C
Download Catalogue

Description

  • Data saved directly on USB Pen drive in an MS Excel compatible file
  • Microprocessor based linearised for J/K/R Thermocouples and PT100 temperature sensors.
  • Auto cold junction compensation for thermocouples and 3 wire input for PT100
  • Rate of logging settable by user in Mins:Secs
  • Digital offset user settable
  • Heat/Cool mode for control action user settable
  • Set Point for temperature control user settable
  • Internal Real Time Clock with battery backup for saving values along with Date and Time
  • No need of any complicated or additional software for managing data
  • Saving data on Pen drive allows a very large amount of storage space at very low cost.

Additional information

Your custom text or HTML.

Weight 700 lbs
Display

4+4 digit 0.56” 7 segment Red LED
Sensor

J,K,R & 3 wire PT100
Range

J T/C : 0 to 750˚C K T/C : 0 to 1250˚C
R T/C : 0 to 1700˚C
PT100: -100.0 to +600.0˚C
Accuracy

±0.1% of Full Scale ± 1 digit
Relay Logic

Programmable as Heater/Cooler logic
On/Off or time proportional with 15 sec
cycle time for heater logic
On/Off for cooler logic
5 Amps/220V AC Relay Contact outputs
Proportional Band

-7.0˚C to +3.0˚C around set point with
10% per degree cut
Hysterisis Band

Settable from 0˚C to 20.0˚C
Percentage Power

User programmable from 0% to 100% to
avoid overshoots and save power
Offset Band

Settable from -20.0˚C to +20.0˚C
Memory

Non-volatile EEPROM to save settings
Configuration Lock

Open terminals 4&5 to lock the Sensor
type, Relay logic and Set Limits
Supply

220V AC ± 15% @ 50/60Hz
Dimensions

96mm x 96mm x 135mm.
Cut Out : 91mm x 91mm
Weight

800 grams

Additional Information

Display:
4+4 digit 0.56” 7 segment Red LED
Sensor:
J,K,R & 3 wire PT100
Range:
J T/C : 0 to 750˚C K T/C : 0 to 1250˚C R T/C : 0 to 1700˚C PT100: -100.0 to +600.0˚C
Accuracy:
±0.1% of Full Scale ± 1 digit
Relay Logic:
Programmable as Heater/Cooler logic On/Off or time proportional with 15 sec cycle time for heater logic On/Off for cooler logic 5 Amps/220V AC Relay Contact outputs
Proportional Band:
-7.0˚C to +3.0˚C around set point with 10% per degree cut
Hysterisis Band:
Settable from 0˚C to 20.0˚C
Percentage Power:
User programmable from 0% to 100% to avoid overshoots and save power
Offset Band:
Settable from -20.0˚C to +20.0˚C
Memory:
Non-volatile EEPROM to save settings
Configuration Lock:
Open terminals 4&5 to lock the Sensor type, Relay logic and Set Limits
Supply:
220V AC ± 15% @ 50/60Hz
Dimensions:
96mm x 96mm x 135mm. Cut Out : 91mm x 91mm
Weight:
800 grams
