160-COND – Online Conductivity Controller with 2 set limits and 4-20mA output

SKU: 160-COND
Download Catalogue

Description

  • Auto/Manual temperature compensation selectable
  • Conductivity and TDS selectable from front panel
  • Cell Factor selectable for both 1.0 and 0.1
  • 4 Step Range selection 0.1µs to 199.9ms for conductivity
  • Digital calibration for Conductivity/TDS
  • Auto Temp Compensation using PT100 sensor
  • Dual set limit with separate relay outputs
  • Settable hysteresis for both set limits
  • Bright Red LED display with separate display for set limit-1
  • Aesthetically designed front panel with membrane switches and ABS cabinet

Frequently Asked Questions — Model 160-COND

What is the 160-COND conductivity controller?

The 160-COND is an online dual-limit conductivity controller by Countronics. Four conductivity ranges (0.1 μS to 199.9 mS), two independent relay outputs, 4-20mA output for SCADA, and auto temperature compensation via PT100.

What does dual-limit mean?

Two independently settable set points each with its own relay. Relay 1 can activate a blowdown valve at a high conductivity limit; Relay 2 can activate dosing at a low limit — automatic two-stage conductivity control.

What is the difference between 160-COND and 5500?

5500 is display-only — no relay or control. 160-COND is a full controller with dual relays and 4-20mA output. Choose 5500 for monitoring only; 160-COND when automatic control is needed.

Does 160-COND have a 4-20mA output?

Yes. 4-20mA output connects to PLCs, SCADA, or data loggers for remote conductivity monitoring alongside local display and relay control.

What industries use the 160-COND?

Boiler feed water, RO plants, cooling tower blowdown, pharmaceutical water systems, food processing, and swimming pool treatment — any process requiring automatic conductivity-based water quality control.

Who manufactures the 160-COND?

Manufactured by Countronics, ISO 9001:2015 certified, established 1978, Ghaziabad. Contact: +91-9810536887.

Technical Specifications

Display

0.56” Red LED 7 segment Display for Conductivity/TDS
0.56” Red LED 7 segment Display for Set-Limit-1

Resolution

Conductivity: 0.01ms or 0.01µs depending on range & Cell factor TDS: 1ppm

Auto Temp. Comp

0-100˚C using PT100 external sensor

Manual Temp. Comp

Settable from front panel from 0-100.0˚C

Cond/TDS Calibration

Digital calibration by factor multiplication from 0.75-1.25

Recorder Output

Isolated 4-20mA => 0-2000 (for whatever unit and resolution selected
(Maximum termination 250Ω)

Control Output

Two set of NO-P-NC, 5 Amps potential free Relay Contacts
Relay 1 ON, for Cond/TDS < Set Limit1 – Hysterises1, Relay 1 OFF, for Cond/TDS > Set Limit1
Relay 2 OFF, for Cond/TDS < Set Limit2,Relay 2 ON, for Cond/TDS > Set Limit2 + Hysterises2

Accuracy

0.5% ± 1 Digit

Supply

220V AC ±10% @ 50Hz

Enclosure

Plastic (ABS). Size -96x96x110mmm

Low Voltage

Set at 10.5V internally. For testing 12V Battery AH

Weight

900 grams

Supplied worldwide. Countronics ships instruments to customers across Asia, the Middle East, Africa and the Americas. Every model can be customised for 12 V DC, 24 V DC or 110 V / 60 Hz on request, as well as the standard 230 V / 50 Hz. Mention your supply voltage and country when you ask for a quote, or see International / Export.
