2500 – 6 digit Programmable Counter with 2 set limits, (Size: 72x72mm)

SKU: 2500
Download Catalogue

Description

  • 6 Digit Preset Counter
  • Dual Limits settable with dual relay output
  • Programmable Scale Factor of 0.001 to 999.999
  • Pre-settable Batch Counter
  • Cumulative 6 Digit Counter
  • Up/Down Counting Selectable
  • Normal/Auto-Reset with Time Setting
  • Non-Volatile memory to hold settings and counts
  • Program configuration lock at rear
  • External Setting for Slow/Fast for noiseless operation

Technical Specifications

Display

6 Digit, 7 segment LED display (0.3” height)

Range

Selectable least count of 0.001, 0.01, 0.1, 1. Maximum Count of 999999

Set Points

Two set points each programmable from 0.001 to 999999

Batch Limit

Batch limit setting from 0 to 999

Operating Modes

a. Auto Mode b. Manual Mode c. No limit Mode (Event Counter)

Count Inputs

a. Voltage Pulse : 3V to 30V DC amplitude from proximity switch
b. Potential free contact from limit switch, relay or micro switch

Input Frequency

a. 0 to 30 Hz b. 0 to 1 KHz

Sensor Supply

10V DC, short circuit protected

Scale Factor

Programmable from 0.001 to 999.999

Reset Input

a. Front Panel b. Remote reset

Relay Outputs

Two relays, one for each set point; 1 C/O (SPDT) rated at 5Amp @ 230 V AC

Memory Retention

10 years

Configuration Lock

Via rear DIP-Switch to avoid changes in configured parameters by mistake

Mounting

Panel Mounting

Size

72mm x 72mm

Weight

Approx. 375 gms.

Operating Temp.

0-50 degeesC

Humidity

95% RH

Supplied worldwide. Countronics ships instruments to customers across Asia, the Middle East, Africa and the Americas. Every model can be customised for 12 V DC, 24 V DC or 110 V / 60 Hz on request, as well as the standard 230 V / 50 Hz. Mention your supply voltage and country when you ask for a quote, or see International / Export.
